| Compliance | |
|---|---|
| LED Wind Cone | ICAO Annex 14 Volume 1, 6th Edition, Section 5.1.1. |
| Optical | |
| Obstruction Light | 3 options – No Light, Visible L810, Visible+IR L810 |
| Internal Light | 12W cool white LED luminaire |
| Output | 580 lumens at source |
| Configuration | Internally lit |
| LED Life Expectancy | Up to 60,000 hours |
| Operation Profile | Dusk to Dawn |
| Electrical | |
| Configuration | Electrical system or generators |
| Voltage | 95-264VAC |
| Current | 2.8-6.6A with Constant Current Regulator (CCR) |
| RF Controller | Optional Radio Frequency Controller for on/off control |
| Mechanical | |
| Configuration | Counter-weighted Aluminum tilt pole with single concrete base |
| Overall Height | 18’9” or custom size in 1’ increments from 8’ |
| Tilt Mechanism | Counter-balanced tilt at 4’6” |
| Swivel | Patented maintenance-free sealed aluminum swivel |
| Mounting | Aluminum base plate with 4-bolt pattern for concrete mount. 3⁄4″ hot dipped galvanized anchor bolts |
| Frangibility | Optional fused bolt mounting system |
| Sock Dimensions | 36” x 12’ |
| Fabric | Polyethylene coated colorfast 4.5oz nylon Orange/White, Solid Orange or custom |
| Weight | 140 lbs. (20 cu. ft.) |
| Height | 20’ x 3” |
